Zebra DS457 Series User Manual

Standard Default Parameters A - 3
Presentation Mode Field of View 609 F1h 61h Small 7-9
Frame Rate 674 F1h A2h Auto 7-10
Image Capture Autoexposure 360 F0h 68h Enable 7-12
Image Capture Illumination 361 F0h 69h Enable 7-12
Fixed Gain 568 F1h 38h 50 7-13
Exposure Time 567 F4h F1h 37h 100 (10 ms) 7-13
Snapshot Mode Timeout 323 F0h 43h 0 (30 seconds) 7-14
Snapshot Aiming Pattern 300 F0h 2Ch Enable 7-14
Image Cropping 301 F0h 2Dh Disable 7-15
Crop to Pixel Addresses 315, 316,
317, 318
F4h F0h 3Bh;
F4h F0h 3Ch;
F4h F0h 3Dh;
F4h F0h 3Eh
0 top, 0 left, 479
bottom,
751 right
7-16
Image Resolution 302 F0h 2Eh Full 7-17
Image Brightness (Target White) 390 F0h 86h 180 7-18
Image File Format Selection 304 F0h 30h JPEG 7-19
JPEG Image Options 299 F0h 2Bh Quality 7-19
JPEG Quality Value 305 F0h 31h 65 7-20
JPEG Size Value 561 F1h 31h 160 (164K) 7-20
Image Enhancement 564 F1h 34h Off 7-21
Image Edge Sharpening 664 F1h 98h Low 7-22
Image Contrast Enhancement 666 F1h 9Ah Enable 7-23
Image Rotation 665 F1h 99h 0 7-24
Bits per Pixel (BPP) 303 F0h 2Fh 8 BPP 7-25
Signature Capture 93 5Dh Disable 7-26
Signature Capture Image File Format
Selection
313 F0h 39h JPEG 7-27
Signature Capture Bits per Pixel (BPP) 314 F0h 3Ah 8 BPP 7-28
Signature Capture Width 366 F4h F0h 6Eh 400 7-28
Signature Capture Height 367 F4h F0h 6Fh 100 7-29
Signature Capture JPEG Quality 421 F0h A5h 65 7-29
Table A-1 Standard Default Parameters Table (Continued)
