Zebra DS457 Series User Manual

A - 4 DS457-XX20004ZZWW Fixed Mount Imager Integration Guide
Video Mode Format Selector 916 F2h 94h JPEG 7-30
Video View Finder 324 F0h 44h Disable 7-30
Target Video Frame Size 328 F0h 48h 2200 bytes 7-31
Video View Finder Image Size 329 F0h 49h 1700 bytes 7-31
Video Resolution 667 F1h 9Bh 1/4 resolution 7-32
SSI Host Parameters
Select SSI Host N/A N/A N/A 8-9
Baud Rate 156 9Ch 9600 8-10
Parity 158 9Eh None 8-11
Check Parity 151 97h Disable 8-12
Software Handshaking 159 9Fh ACK/NAK 8-12
Host RTS Line State 154 9Ah Low 8-13
Decode Data Packet Format 238 EEh Send Raw Decode
Data
8-13
Host Serial Response Time-out 155 9Bh 2 sec 8-14
Host Character Time-out 239 EFh 200 msec 8-15
Multipacket Option 334 F0h 4Eh Option 1 8-16
Interpacket Delay 335 F0h 4Fh 0 ms 8-17
Event Reporting
Decode Event 256 F0h 00h Disable 8-18
Boot Up Event 258 F0h 02h Disable 8-19
Parameter Event 259 F0h 03h Disable 8-19
Serial Host Parameters
Serial Host Types N/A N/A Standard RS-232 9-5
Baud Rate N/A N/A 9600 9-7
Parity Type N/A N/A None 9-8
Data Bits N/A N/A 8-Bit 9-8
Check Receive Errors N/A N/A Enable 9-9
Hardware Handshaking N/A N/A None 9-10
Software Handshaking N/A N/A None 9-12
Table A-1 Standard Default Parameters Table (Continued)
Parameter
Parameter
Number
SSI Number Default
Page
Number
1
User selection is required to configure this interface and this is the most common selection.
