A - 8 DS457-XX20004ZZWW Fixed Mount Imager Integration Guide
UPC-E1 Preamble 36 24h System Character 12-23
Convert UPC-E to A 37 25h Disable 12-24
Convert UPC-E1 to A 38 26h Disable 12-24
EAN-8/JAN-8 Extend 39 27h Disable 12-25
Bookland ISBN Format 576 F1h 40h ISBN-10 12-26
UCC Coupon Extended Code 85 55h Disable 12-27
Coupon Report 730 F1h DAh New Coupon Format 12-28
ISSN EAN 617 F1h 69h Disable 12-29
Code 128
Code 128 8 08h Enable 12-30
Set Length(s) for Code 128 209, 210 D1h D2h Any Length 12-30
GS1-128 (UCC/EAN-128) 14 0Eh Enable 12-32
ISBT 128 84 54h Enable 12-32
ISBT Concatenation 577 F1h 41h Disable 12-33
Check ISBT Table 578 F1h 42h Enable 12-34
ISBT Concatenation Redundancy 223 DFh 10 12-34
Code 128 Security Level 751 F3h EFh Security Level 1 12-35
Code 128 Reduced Quiet Zone 1208 F8h 04h B8h Disable 12-36
Ignore Code 128 <FNC4> 1254 F8h 04h E6h Disable 12-36
Code 39
Code 39 0 00h Enable 12-37
Trioptic Code 39 13 0Dh Disable 12-37
Convert Code 39 to Code 32
(Italian Pharmacy Code)
86 56h Disable 12-38
Code 32 Prefix 231 E7h Disable 12-38
Set Length(s) for Code 39 18, 19 12h 13h 2 to 55 12-39
Code 39 Check Digit Verification 48 30h Disable 12-40
Transmit Code 39 Check Digit 43 2Bh Disable 12-41
Code 39 Full ASCII Conversion 17 11h Disable 12-41
Code 39 Security Level 750 F3h EEh Security Level 1 12-42
Table A-1 Standard Default Parameters Table (Continued)
Parameter
Parameter
Number
SSI Number Default
Page
Number
1
User selection is required to configure this interface and this is the most common selection.

Zebra DS457 Series Specifications

General

Connectivity	USB, RS-232
Decode Capability	1D, 2D, PDF417, Postal Codes
Scan Rate	Up to 60 scans per second
Supported Barcode Types	UPC/EAN, Code 39, Code 128, QR Code, Data Matrix, PDF417, Postal Codes
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Humidity	5% to 95% (non-condensing)
Power Consumption	2.5 W (typical)
