Zebra DS457 Series User Manual

Standard Default Parameters A - 7
IDC Minimum Text Length 656 F1h 90h 00 12-13
IDC Maximum Text Length 657 F1h 91h 00 12-13
IDC Captured Image Brighten 654 F1h 8Eh Enable 12-14
IDC Captured Image Sharpen 658 F1h 92h Enable 12-15
IDC Border Type 829 F2h 3Dh None 12-16
IDC Delay Time 830 F2h 3Eh 000 12-17
IDC Zoom Limit 651 F1h 8Bh 000 12-17
IDC Maximum Rotation 652 F1h 8Ch 00 12-18
Enable/Disable All Code Types N/A N/A N/A 12-9
UPC/EAN
UPC-A 1 01h Enable 12-10
UPC-E 2 02h Enable 12-10
UPC-E1 12 0Ch Disable 12-11
EAN-8/JAN 8 4 04h Enable 12-11
EAN-13/JAN 13 3 03h Enable 12-12
Bookland EAN 83 53h Disable 12-12
Decode UPC/EAN/JAN Supplementals
(2 and 5 digits)
16 10h Ignore 12-13
User-Programmable Supplementals
Supplemental 1:
Supplemental 2:
579
580
F1h 43h
F1h 44h
12-16
UPC/EAN/JAN Supplemental
Redundancy
80 50h 10 12-16
UPC/EAN/JAN Supplemental AIM ID
Format
672 F1h A0h Combined 12-17
UPC Reduced Quiet Zone 1289 F8h 05h 09h Disable 12-18
Transmit UPC-A Check Digit 40 28h Enable 12-19
Transmit UPC-E Check Digit 41 29h Enable 12-19
Transmit UPC-E1 Check Digit 42 2Ah Enable 12-20
UPC-A Preamble 34 22h System Character 12-21
UPC-E Preamble 35 23h System Character 12-22
Table A-1 Standard Default Parameters Table (Continued)
Parameter
Parameter
Number
SSI Number Default
Page
Number
1
User selection is required to configure this interface and this is the most common selection.

Zebra DS457 Series Specifications

General

Connectivity	USB, RS-232
Decode Capability	1D, 2D, PDF417, Postal Codes
Scan Rate	Up to 60 scans per second
Supported Barcode Types	UPC/EAN, Code 39, Code 128, QR Code, Data Matrix, PDF417, Postal Codes
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Humidity	5% to 95% (non-condensing)
Power Consumption	2.5 W (typical)
