A - 6 DS457-XX20004ZZWW Fixed Mount Imager Integration Guide
OCR-A Variant 684 F1h ACh Full ASCII
11-3
OCR-B 681 F1h A9h Disable
11-5
OCR-B Variant 685 F1h ADh Full ASCII
11-6
MICR E13B 682 F1h AAh Disable
11-9
US Currency 683 F1h ABh Disable
11-10
OCR Orientation 687 F1h AFh
0
o
11-10
OCR Lines 691 F1h B3h 1
11-12
OCR Min Char 689 F1h B1h 3
11-13
OCR Max Char 690 F1h B2h 100
11-13
OCR Subset 686 F1h AEh Selected font variant
11-14
OCR Quiet Zone 695 F1h B7h 50
11-14
OCR Template 547 F1h 23h 99999999
11-15
OCR Check Digit Modulus 688 F1h B0h 1
11-24
OCR Check Digit Multiplier 700 F1h BCh 121212121212
11-25
OCR Check Digit Validation 694 F1h B6h None
11-26
Inverse OCR 856 F2h 58h Regular Only
11-30
OCR Redundancy 1770 F8h 06h EAh Level 1
11-31
Intelligent Document Capture (IDC) Parameters
IDC Operating Mode 594 F1h 52h Off
12-6
IDC Symbology 655 F1h 8Fh 001
12-7
IDC X Coordinate 596 F4h F1h 54h -151
12-8
IDC Y Coordinate 597 F4h F1h 55h -050
12-8
IDC Width 598 F1h 56h 0300
12-9
IDC Height 599 F1h 57h 0050
12-9
IDC Aspect 595 F1h 53h 000
12-10
IDC File Format Selector 601 F1h 59h JPEG
12-10
IDC Bits Per Pixel 602 F1h 5Ah 8 BPP
12-11
IDC JPEG Quality 603 F1h 5Bh 065
12-12
IDC Find Box Outline 727 F1h D7h Disable
12-12
Table A-1
Standard Default Parameters Table (Continued)
Parameter
Parameter
Number
SSI Number Default
Page
Number
1
User selection is required to configure this interface and this is the most common selection.
