A - 10 DS457-XX20004ZZWW Fixed Mount Imager Integration Guide
MSI
MSI 11 0Bh Disable 12-62
Set Length(s) for MSI 30, 31 1Eh 1Fh 4 to 55 12-63
MSI Check Digits 50 32h One 12-64
Transmit MSI Check Digit 46 2Eh Disable 12-65
MSI Check Digit Algorithm 51 33h Mod 10/Mod 10 12-65
MSI Reduced Quiet Zone 1392 F8h 05h 70h Disable 12-66
Chinese 2 of 5
Chinese 2 of 5 408 F0h 98h Disable 12-67
Matrix 2 of 5
Matrix 2 of 5 618 F1h 6Ah Disable 12-67
Matrix 2 of 5 Lengths 619, 620 F1h 6Bh
F1h 6Ch
1 Length: 14 12-68
Matrix 2 of 5 Check Digit 622 F1h 6Eh Disable 12-69
Transmit Matrix 2 of 5 Check Digit 623 F1h 6Fh Disable 12-69
Korean 3 of 5
Korean 3 of 5 581 F1h 45h Disable 12-70
Inverse 1D 586 F1h 4Ah DS457-SR/HD/DL:
Regular
DS457-DP:
Inverse Autodetect
12-71
Postal Codes
US Postnet 89 59h Disable 12-72
US Planet 90 5Ah Disable 12-72
Transmit US Postal Check Digit 95 5Fh Enable 12-73
UK Postal 91 5Bh Disable 12-73
Transmit UK Postal Check Digit 96 60h Enable 12-74
Japan Postal 290 F0h 22h Disable 12-74
Australia Post 291 F0h 23h Disable 12-75
Australia Post Format 718 F1h CEh Autodiscriminate 12-76
Netherlands KIX Code 326 F0h 46h Disable 12-77
Table A-1 Standard Default Parameters Table (Continued)
Parameter
Parameter
Number
SSI Number Default
Page
Number
1
User selection is required to configure this interface and this is the most common selection.

Zebra DS457 Series Specifications

General

Connectivity	USB, RS-232
Decode Capability	1D, 2D, PDF417, Postal Codes
Scan Rate	Up to 60 scans per second
Supported Barcode Types	UPC/EAN, Code 39, Code 128, QR Code, Data Matrix, PDF417, Postal Codes
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Humidity	5% to 95% (non-condensing)
Power Consumption	2.5 W (typical)
