Zebra ZXP Series 3 Service Manual

4: Troubleshooting
Troubleshooting Procedures
P1061317-002 Zebra ZXP Series 3 Card Printer Service Manual 95
Example • Pale or inconsistent results
Printing shows very pale or inconsistent results.
Possible Cause:
• The ribbon cartridge may have been stored improperly or is damaged.
Solution:
• Change the ribbon cartridge, and print again. Refer to Installing the Ribbon Cartridge
on page 66.
Possible Cause:
• The cards may not meet specifications. Refer to Specifications on page 6.
Solution:
• Use a different supply of cards.
Possible Cause:
• There may be dust or embedded contamination on the elements of the printhead.
Solution:
• Clean the printhead. Refer to Cleaning the Printhead on page 350.
Possible Cause:
• Printing on wrong side of writable back cards.
Solution:
• Reverse direction of cards in feeder.
Possible Cause:
• Improperly adjusted print intensity/density.
Solution:
• Adjust the print intensity/density. Refer to Image Control on page 61.

Zebra ZXP Series 3 Specifications

General

Color	No
Card size	54 x 86 mm
Card types	Magnetic stripe (ISO 7811), PVC, PVC Composite, Smart card
Card feeder	Yes
Print technology	Dye-sublimation
Maximum resolution	300 DPI
Print speed (color)	180 card/h
Print speed (monochrome)	750 card/h
Printing media thickness	762 µm
Duplex print speed (color)	140 card/h
Display	LCD
Certification	FCC, CE, UL, CUL
Product color	Grey, White
Internal memory	32 MB
Built-in barcodes	EAN13, EAN8, Interleaved 2/5, PDF417, UPC-A
Total input capacity	100 sheets
Display number of characters	16
Compatible operating systems	Windows
Storage temperature (T-T)	-5 - 70 °C
Operating temperature (T-T)	15 - 30 °C
Storage relative humidity (H-H)	20 - 70 %
Operating relative humidity (H-H)	20 - 65 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Interface	USB
Optional connectivity	Ethernet, USB 2.0

Weight and Dimensions

Weight	5530 g
Dimensions (WxDxH)	201 x 368 x 309 mm
