Table 203: Measurement modes supported by (F)PHxPTOC stages
Measurement mode (F)PHLPTOC PHHPTOC PHIPTOC
RMS x x
DFT x x
Peak-to-Peak x x
P-to-P + backup x
Wide P-to-P
x
1)
1) Available only in REG615 standard configurations C and D
For a detailed description of the measurement modes, see the
Measurement modes section in this manual.
4.1.1.6 Timer characteristics
(F)PHxPTOC supports both DT and IDMT characteristics. The user can select the
timer characteristics with the Operating curve type and Type of reset curve settings.
When the DT characteristic is selected, it is only affected by the Operate delay time
and Reset delay time settings.
The protection relay provides 55 IDMT characteristics curves, of which seven comply
with the IEEE C37.112 and six with the IEC 60255-3 standard. Two curves follow the
special characteristics of ABB praxis and are referred to as RI and RD. One user
programmable curve can be used if none of the standard curves are applicable. In
addition to this, there are 39 curves for recloser applications. The DT characteristics
can be chosen by selecting the Operating curve type values "ANSI Def. Time" or "IEC
Def. Time". The functionality is identical in both cases.
The timer characteristics supported by different stages comply with the list in the IEC
61850-7-4 specification, indicate the characteristics supported by different stages:
Table 204: Timer characteristics supported by different stages
Operating curve type
(F)PHLPTOC PHHPTOC
(1) ANSI Extremely Inverse x x
(2) ANSI Very Inverse x
(3) ANSI Normal Inverse x x
(4) ANSI Moderately Inverse x
(5) ANSI Definite Time x x
(6) Long Time Extremely Inverse x
(7) Long Time Very Inverse x
(8) Long Time Inverse x
(9) IEC Normal Inverse x x
(10) IEC Very Inverse x x
Table continues on next page
1MRS758755 A Section 4
Protection functions
REC615 and RER615 205
Technical Manual
