Appendix A – Specifications and ordering information
Acterna ANT-5 Page 117
9. Appendix A – Specifications and ordering information
Note: These specifications are valid under the nominal operating conditions, unless
otherwise stated. Error limits are stated as operating errors or as intrinsic errors and
variations, these terms being as defined in IEC 359.
9.1 General
Serial port....................................................................... 9-way, male, D-type connector
PC Card slot (BN4565/01 only) .............................................. Single, standard PC Card
Supported PC Cards (BN4565/01 only) ..............................PCMCIA/JEIDA Types I & II
5V SRAM cards with grounding/EMC clips
MS-DOS compatible file system
CompactFlash card slot (BN 4565/02 onwards)... Single, standard CompactFlash Card
Supported CompactFlash cards .................................................................. Types I & II
BN4565/01 series
Dimensions (LxWxH)................................................ approx. 258mm x 199mm x 95mm
(10.1in. x 7.8in. x 3.7in.)
Weight ......................................................................................approx. 2.35 kg (5.18 lb)
BN 4565/02 onwards
Dimensions (LxWxH)................................................ approx. 275mm x 197mm x 76mm
(10.95in. x 7.9in. x 3in.)
Weight ........................................................................................approx. 2.2 kg (4.85 lb)
9.2 External Power Supply
BN4565/01 series
Type ..................................................................................................................... PPS-1
Input .................................................................................100-240V, 0.7A, 50/60Hz, AC
Output ......................................................................................................12V, 2.5A, DC
BN 4565/02 onwards
Type ..................................................................................................................... PPS-2
Input .................................................................................100-240V, 1.6A, 47/63Hz, AC
Output .........................................................................................................19V, 3A, DC
