Appendix C – Serial port and adapter cables
Acterna ANT-5 Page 127
11. Appendix C – Serial port and adapter cables
11.1 Serial port
The ANT-5 serial port is 9-way, male, D-type connector which is wired as a DTE.
1
3
2
4
6
8
5
7
9
Serial port
connections (DTE)
DCD
RD
TD
DTR (+5V)
SGND
DSR
RTS
CTS
RI
11.2 Serial adapter cables
A serial printer cable (K1524), modem cable (K1550) and a null modem cable (K1619)
are available as shown below.
1
2
8
5
4
3
6
7
4
2
7
6
5
3
8
20
25 pin male
Connects to
Printer (DTE)
9 pin female
Connects to
ANT-5 (DTE)
DCD
RD
TD
DTR
DSR
CTS
SGND
RTS
RTS
TD
RD
CTS
DSR
DTR
SGND
DCD
Printer cable K1524
