Appendix A – Specifications and ordering information
Page 122 Acterna ANT-5
9.6.1 Hardware options and order numbers
Option Order Number
STM-1 1310nm BN4565/00.01
STM-1 1550nm BN4565/00.02
STM-1 1310/1550nm BN4565/00.03
STM-1/4 1310/1550nm BN4565/00.14
STM-16
Contact Acterna
9.6.2 Cables
Balanced E1 Cable RJ48 / 2xCF ..........................................................................K1597
For the serial port, a serial printer cable (K1524), modem cable (K1550) and null
modem cable (K1619) are available. See Appendix C – Serial port and adapter
cables.
9.6.3 PC Cards – BN4565/01 series
Acterna Part numbers for compatible PC Cards are as follows:
5V SRAM card, 512 kbyte....................................................................... BN 4548/00.12
5V SRAM card, 1 Mbyte ......................................................................... BN 4548/00.11
5V SRAM card, 2 Mbyte ......................................................................... BN 4564/00.05
Note: If an Ethernet connection is made via the PC Card slot, only 3COM 589 chip-set
PC cards are supported, model numbers 3CCE589EC and 3CCE589ET.
9.6.4 CompactFlash Cards – BN 4565/02 onwards
Optional CompactFlash card 16 Mbyte + adapter................................... BN 4548/00.42
9.6.5 T1 testing
Bit rates using the T1 input impedance of 100Ω can be tested using the E1 BNC Tx
and Rx interfaces on the ANT-5. An optional balum and cables can be purchased from
Acterna, (BN4565/00.78). Contact the nearest Acterna Sales Office or Technical
Assistance Centre for further details.
9.7 Ordering information
Please contact the nearest Acterna Sales Office or Technical Assistance Centre. For
locality information visit our web site, www.acterna.com, or contact the nearest
Regional Sales Office as listed on the back of the manual.
