Introduction
Page 16 Acterna ANT-5
V24 D type 9-way
Male
Serial port connector
12V DC power 2.5mm 12V Power supply input. For use with type
PPS-1 only
Serial port
connector
Attachment
point
12V DC
Ext power
connector
ANT-5
Rear view
BNC
connectors
Ext. clock
connector
Optical
connectors
Side view
ANT-5
RJ48 connector
