Chapter 5 - Maintenance
104 AdeptModules Instruction Handbook, Volume 1: Adept MV Controller Interface, Rev. A
Lubrication Grease
For standard non-cleanroom modules (module part numbers that begin with
90400-XXXXX), Shell Alvania No. 2 grease is recommended. Adept does not supply this
grease for the modules product and purchase this grease from a third-party.
For cleanroom modules (module part numbers that begin with 90401-XXXXX) a special
cleanroom grease is required. This grease is supplied by Adept Technology. The Adept
part number is 90401-04029 for a single tube with 50 cc of grease. Please contact Adept
customer service to order this grease.
Grease Adapter Nozzle
The grease fittings on the modules have a 4.5 mm (0.8 inch) diameter and a small
ballcheck in the center. A special adapter is required for these fittings.
The grease adapter nozzle is supplied by Adept Technology. The Adept part number is
90400-04100. Please contact Adept Customer Service to order a grease adapter nozzle.
Lubrication Procedures
1. Remove the plastic black circular cap(s) from the module. The cap is
approximately 10 mm (0.5 inch) diameter.
• The H-Module has two black caps located on each side of the module at the
end of the module opposite the motor.
• The M-Module has a single black cap located on the same side of the module
as the cable connections and near the motor end of the module.
Table 5-1. Lubrication Schedule
Module Stroke
Length (mm)
Estimated
Module
travel
distance
(meters)
Cycle
Time
(seconds)
Total
number
of hours
(hours)
Lubrication
Interval for
1 Shift/day
5 days/week
40 hrs/week
(weeks)
Lubrication
Interval for
2 Shifts/day
6 days/week
96 hrs/week
(weeks)
Lubrication
Interval for
3 Shifts/day
7days/week
168 hrs/week
(weeks)
130 0.13 1.0 10,684 267 111 64
230,250 0.24 1.5 8,680 217 91 52
300,330,350 0.325 2.0 8,550 214 89 51
400,430,450 0.425 2.5 8,170 204 85 49
500,530,550,600 0.55 3.0 7,576 189 79 45
750,800 0.78 3.5 6,232 156 65 37
950,1000,1200 1.0 4.0 5,555 139 59 33
1400 to 2000 1.4 4.5 4,464 112 47 27
