2.17 Grounding Information
Adept MV Controller Grounding
The detachable three-wire power cord connects to the power source and the protective
ground. The protective ground conductor (colored green/yellow) in the power cord is
internally connected to the exposed metal parts of the Adept MV Controller. To ensure
electrical-shock protection, the protective ground conductor must be connected to a
properly grounded power source (see Figure 2-17).
Adept PA-4 Power Chassis Grounding
The protective ground conductor (colored green/yellow) of the Adept PA-4 Power
Chassis is internally connected to the accessible metal parts of the power chassis. To
ensure electrical-shock protection, this must be connected to a properly grounded power
source.
