Chapter 6 -
T
echnical Specification
112
AdeptModules Instruction Handbook, V
olume 1:
Adept MV Controller Interface, Re
v
.
A
Adept MV
-19 Controller Dimensions
Figure 6-2.
Adept MV
-19 Dimensions
®
290 mm
(11.4 in.)
52 mm
(2 in.)
290 mm
(11.4 in.)
431 mm
(17 in.)
Front View
Side View
Top View
431 mm
(17 in.)
479 mm
(19 in.)
136 mm
(5.4 in.)
18 mm
(0.7 in.)
