adept technology MV Instruction Handbook

Installing Non-Adept Peripherals in an A-Series System
AdeptModules Instruction Handbook, Volume 1: Adept MV Controller Interface, Rev. A 43
2.14 Installing Non-Adept Peripherals in an A-Series System
Third-party monitors, keyboards, and pointing devices can be used with the Adept MV
Controller system. The equipment must be compatible with certain standards to work
successfully with the MV controller.
Third-Party Monitor Compatibility
To use a color monitor other than the one supplied by Adept, ensure that the monitor
selected meets the specifications shown in Table 2-2. Refer to the Adept MV Controller
User's Guide for more information and specifications
Table 2-2. Monitor Compatibility Specifications
Third-Party Keyboard Compatibility
The Adept MV controller can interface to keyboards that are “AT” compatible and use a
standard DIN 5 connector.
Third-Party Pointing Device Compatibility
The Adept MV controller can interface to any serial mouse, trackballs or other pointing
device that uses the Microsoft mouse protocol (1200 bps). The connector must be a 9-pin
D-sub.
This port can alternatively be used for a touchscreen using ELO Touchsystems protocol.
To install a touchscreen, disconnect any other pointing devices. The MV controller will not
support the use of more than one pointing-type device at a time.
Video Display Resolution 1024 x 768 Pixels
Frame Rate 60 Hz
Format Non-interlaced
Line Rate 48.363 kHz
Dot Rate 65.000 MHz
Video Signal Analog RGB
Signal Level 0 - 0.7 Vp-p
Input Impedance 75 ohm ±5% at 100 kHz
