Chapter 2 - Installation

62 AdeptModules Instruction Handbook, Volume 1: Adept MV Controller Interface, Rev. A

Typical AC Power Installation Diagrams

Figure 2-19. Typical 380-415 VAC Connection

Figure 2-20. Typical 3-Phase 200-240 VAC Connection

L1 PE N L1

F4 10A

Adept PA-4

3Ø 380–415V~

Adept MV-8/MV-19

1Ø 200-240V~

3Ø

380–415V~

20A

380–415V~

200–240V~



Note: F4 is user-supplied.

L1 PE L2 L1

F5 10AF4

3Ø

200–240V~

20A

200–240V~

Adept PA-4

3Ø 200–240V~

Adept MV-8/MV-19

1Ø 200-240V~

Note: F4 and F5 are user-supplied.
