adept technology MV Instruction Handbook

Chapter 2 - Installation
38 AdeptModules Instruction Handbook, Volume 1: Adept MV Controller Interface, Rev. A
Figure 2-4. Installing Mounting Brackets on an Adept PA-4 Power Chassis
M4 x 25mm pan-head screw
(2 places)
M4 x 10mm pan-head screw
M4 x 25mm pan-head screw
(2 places)
M4 x 10mm pan-head screw
Rack Mount – Flush
Panel Mount
To Install Mounting Brackets on Adept PA-4
Power Chassis:
• Remove (and discard) 3 existing countersunk
screws from the side of the chassis at locations shown
in drawing.
• Place bracket in desired position and secure
with indicated M4 pan-head screws and washers from
accessories kit.
• Repeat process for other side of chassis. If the
power chassis is joined to an Adept MV controller,
the position of the screws is different than on the side
of the controller. See the controller drawing.
