Chapter 2 - Installation
34 AdeptModules Instruction Handbook, Volume 1: Adept MV Controller Interface, Rev. A
2.9 Installation of the Adept MV Controller and the Adept PA-4
Power Chassis
Joining an Adept PA-4 Power Chassis to an Adept MV Controller
The Adept PA-4 power chassis can be joined to the Adept MV-5/10 (or the MV-19)
controller using the brackets supplied in the accessory kit. They must be joined at the top
and bottom, as described in the following paragraphs.
Figure 2-1. Joining the Power Chassis and Controller at the Top
Top view with covers removed
Adept MV Controller Adept PA-4 Power Chassis
M4 x 8
flat-head
Phillips
screws
(four each)
