AdeptModules Instruction Handbook, Volume 1: Adept MV Controller Interface, Rev. A 105
• The S and Sz-Modules have a single black cap located on the same side as the
motor housing at the end of the module opposite the motor.
2. Move the module slider until the grease nipple(s) can be seen through the access
hole(s).
• The slider of the H-Module must be moved to the end of the module travel.
• The slider of the M-Module must be moved to a position 10 mm (0.5 inch)
from the motor end.
• The slider of the S- and Sz-Module must be moved to a position 35 mm (1.5
inch) from the end opposite the motor.
3. Fill the module with the appropriate amount of grease.
• The H-Module requires 20 cc (2/3 oz.) of grease. Fill each side with
approximately 10 cc (1/3 oz.).
• The M-Module requires 10 cc (1/3 oz.).
• The S- and Sz-Modules require 2.0 cc (0.1 oz.).
4. Replace the black plastic cap(s) on the modules.
5.3 Connectors and Pins
NOTE: All four encoder connectors have the same pin assignments for
diagnostic purposes. Axis encoder connectors can be interchanged,
provided that no attempt is made to enable the associated axis.
Connector Pins and Inserter/Extractor Tools
The modules and spare motors are supplied with JAE connectors with crimp style pins. If
these pins need to be repaired or replaced, additional pins and an inserter/extractor tool
are required.
The motor pins are the larger of the two pins. Adept Technology has a limited supply of
these pins to send to customers on request. Please contact Adept Technology Customer
Service.
Description JAE Part Number
Encoder Pins 030-51906-800
Motor Pins 030-51928-800
