178 Chapter 10
Command Reference
:DISP:TEXT1:FMSD:DATA
:DISP:TEXT1:FMSD:DATA
Syntax :DISPlay[:WINDow]:TEXT1[:DATA]:FMSD:DATA <numeric 1>,<numeric 2>
:DISPlay[:WINDow]:TEXT1[:DATA]:FMSD:DATA?
Description Sets the value of the highest digit when displaying both the primary and secondary
parameters in the fixed point display. The parameter is always fixed to the same value,
regardless of this setting, if the following conditions are met:
• Deviation is displayed as a percentage in the deviation measurement mode.
• The resulting D and Q of the secondary parameter is displayed.
Parameters
If one of the settable values is not specified for the parameter, the minimum possible value,
which is larger than the specified parameter value, is set. If the specified parameter exceeds
the maximum value, the maximum value is set.
MAX or MIN can be used to specify the parameters.
Query response {numeric 1},{numeric 2}<newline><^END>
Related commands :DISP:TEXT1:FMSD on page 177
:CALC1:MATH:EXPR:NAME on page 148
:CALC1:MATH:STAT on page 149
:CALC2:MATH:EXPR:NAME on page 151
:CALC2:MATH:STAT on page 152
Equivalent key
sequence
[Disp Mode]( [Blue] - [Freq] ) - FixMsd - MsdEnt
<numeric 1> <numeric 2>
Description The value of the highest digit of
the primary parameter.
The value of the highest digit of
the secondary parameter.
Range 1E-12, 10E-12, 100E-12,
1E-9, 10E-9, 100E-9,
1E-6, 10E-6, 100E-6
(only the 9 points listed above)
1E-6, 10E-6, 100E-6,
1E-3, 10E-3, 100E-3,
1, 10, 100,
1E3, 10E3, 100E3,
1E6, 10E6, 100E6
(only the 15 points listed above)
Initial value 1E-9 1
