Appendix B 245

Information for Replacing 4278A with 4288A

Comparison of Interfaces

B. Information for Replacing

4278A with 4288A

Scanner interface

Figure B-3 Pin Assignment

Table B-28 Factory setting

4278A 4288A

Voltage range of input signal drive

power supply

5 V to 6 V 9 V to 15 V

Default Chapter7
