86 Chapter 7
Sorting Based on Measured Result (Comparator Function)
Reading Out Sorting Judgment Result
Reading Out Sorting Judgment Result
You can read out the sorting judgment result (readout value) along with the measured result
by the comparator function according to the correspondences in Figure 7-1. To do this, use
the following commands.
• *TRG on page 128
• :FETC? on page 181
• :READ? on page 186
The comparator sorting result is read out as an integer between 0 and 11, as shown in the
table below.
To display the comparator sorting result in the left side of the instrument setup display area,
use the following command to select the comparator sorting result display page (page
number: 6).
• :DISP:TEXT2:PAGE on page 179
Table 7-2 Relationship between comparator sorting result and readout value
Readout value Comparator sorting result
0 OUT_OF_BINS
1BIN1
2BIN2
3BIN3
4BIN4
5BIN5
6BIN6
7BIN7
8BIN8
9BIN9
10 AUX_BIN
11 Cannot be sorted (an overload is detected).
To Next Page
