Setting Up Measurement Conditions and Display
Sample Program
3. Setting up Measurement
Condition and Display
Sample Program
Example 3-1 shows a sample program to set up the measurement conditions and display.
This program is stored on the sample program disk under the filename “setup.bas.”
This program performs reset, sets up the 4288A as shown in the following table, and saves
the setups into the built-in nonvolatile memory (save location number: 9).
Item Setup
Measurement
parameter
Primary parameter Cp
Secondary parameter D
Measurement signal Frequency 1 kHz
Level 500 mV
Measurement range Auto range mode
Measurement time Long mode
Averaging count 4
Cable length 0 m
Trigger delay time 1 ms
Display ON/OFF ON
Number of display digits for the measurement
result
5
Fixed point display for the measurement result OFF
Deviation
measurement mode
(Primary parameter)
Mode Percentage display
Reference value 10 nF
Deviation
measurement mode
(Secondary
parameter)
Mode OFF
Reference value 0
Page number of the instrument setup display area 4 (the page that displays the measurement signal level
monitor result)
Measurement signal
level monitor
Current OFF
Vo ltag e O N
Beep mode FAIL
