84 Chapter 7
Sorting Based on Measured Result (Comparator Function)
Setting Up Comparator Function
Turning ON/OFF AUX BIN function
To turn ON/OFF the AUX BIN function, use the following command.
• :CALC:COMP:AUXB on page 135
Depending on the ON/OFF state of the AUX BIN function, the sorting result when the
value of the secondary parameter exceeds the limit range varies as shown in Table 7-1.
Setting up condition to make a beep sound
You can select the condition that produces a beep sound based on the comparator sorting
judgment result from the following:
• Beep when the sorting judgment result is OUT_OF_BINS or AUX_BIN
• Beep when the sorting judgment result is BIN1 to BIN9
To set the condition that makes a beep sound, use the following command.
• :CALC:COMP:BEEP:COND on page 136
You can also disable the beep sound. To turn ON/OFF the beep, use either of the following
commands (they have the same function).
• :CALC:COMP:BEEP on page 135
• :SYST:BEEP:STAT on page 191
Table 7-1 Sorting result when measured secondary parameter value exceeds limit range
Primary parameter sorting result AUX BIN function Sorting result
One of BIN1 to BIN9
OFF OUT_OF_BINS
ON AUX_BIN
Not sorted to any BIN Not applicable OUT_OF_BINS
To Next Page
