252 Appendix C
Status Reporting System
Status Register Structure
Issuing the *CLS command will clear all bits from the status byte register.
Table C-1 Status Bit Definitions of Status Byte (STB)
Bit
Position
Name Description
0 to 2 Not used Always 0
3 Questionable Status Register
Summary
Set to “1” when one of the enabled bits in the status event
status register is set to “1.”
4 MAV (Message Available) Set to “1” when the output queue contains data; reset to
“0” when all of the data has been retrieved.
5 Standard Event Status Register
Summary
Set to “1” when one of the enabled bits in the status event
status register is set to “1.”
6 RQS Set to “1” when any of the status byte register bits enabled
by the service request enable register is set to “1”; reset to
“0” when all of the data has been retrieved through serial
polling.
7 Operation Status Register
Summary
Set to “1” when one of the enabled bits in the operational
status register is set to “1.”
