Inlets and valves
6850
6850
Released: April 2004 6850 Series Gas Chromatograph Service Procedures 88
10. If the leaky component is serviceable, such
as vent/inlet fittings, replace them. Other-
wise, replace the EPC module.
See the following diagram of serviceable parts,
Figure 1-28.
Figure 1-26. EPC module serviceable parts
Aluminum bracket
O-rings
Supply fitting
O-ring
Septum purge fitting
