Lesson 1 – Multi-Site Test

519

•There are setup-focus state to perform the site-specific setup, and

query-focus state to perform the site-specific retrieve.

•There are two approaches for site-specified Setup as follows:

•Controlling the Setup/Query-focus state of Site Automatically

•Controlling the Setup-focus state of Sites Manually
