Lesson 2 – DUT Board Design Considerations

539

2-5 Troubleshooting Noise Problems

During test circuit development, you may encounter one or several of the

following problems:

• A correctly specified filter does not cut the signal as required.

• A relay does not disconnect a signal completely.

• A weak signal shows exessive noise.

• A DC reference voltage has high frequency spikes.

Such problems are likely to be caused by poor isolation or crosstalk.

Consider the following measures:

Troubleshooting DUT Board Problems
