Agilent Technologies 93000 SOC Series User Manual

Lesson 4 – Executing the ADC Linearity Test
349
4-3 Uploading Result Waveforms with
the Mixed-Signal Tool
Uploading and displaying ADC result waveforms with the Mixed-
Signal Tool is done in the same way as described in the previous
Unit for the DAC test.
Typical configurations are:
Mixed-Signal Tool Display Configurations
How to Specify Upload Parameters
To specify the contents of the waveform result section:
1 Click the UPLOAD CONFIG button of the Mixed-Signal Tool.
2 Make the settings as displayed below:
(Note the test suite number TS NO may vary, depending on
whether the whole test flow was executed, or an individual test
suite.)
