Agilent Technologies 93000 SOC Series User Manual

Lesson 2 – Setting Up the Waveform Generator
321
2-4 Summary and Discussion
In this lesson, you have learnt about the set up of the arbitrary
waveform generator for the execution of the ADC tests.
You now know what each mixed-signal tool is used for when
setting up the AWG:
• The Analog Setup Tool for hardware settings, sequencer program
definition, waveform memory setup and sampling frequency
specification for the AWG.
• The Mixed-Signal Tool for creating an analog waveform and
downloading it to the AWG.
• The Routing Tool for setting up the signal routing for the ADC test.
