Lesson 4 – Defining the Signal Routing

221

4-4 Activating a Routing Set

Once the Routing File has been downloaded to the tester, each

routing set in the file can be chosen and activated.

A routing set can be chosen in the Test Control window of the

testfunction to be executed, as shown below, or in a test method

by using the Routing.primary(set_number) function.

Specifying the Routing Set for a Testfunction
