Agilent Technologies 93000 SOC Series - Summary and Discussion

Lesson 2 – TIA Setup
495
2-5 Summary and Discussion
In this lesson you learned how to make the settings for a TIA test.
You now know all the test setup parameters for the front-end
module and for the TIA instrument, and understand how these
parameters define the test to be performed.
You further know how to set up TIA pins with the Pin
Configuration Editor, and how to define the routing for the pins to
be used during the test with the Routing Setup Tool.
