Lesson 2 – Waveform Digitizer Setup with the Analog Setup Tool

196

2-8 Summary and Discussion

This lesson has made you familiar with the main capabilities of the

Analog Setup Tool.

You have seen how to use the Analog Setup Tool to set up the High

Speed Digitizer.

You will use the Analog Setup Tool to prepare the analog modules

involved in a mixed-signal test. You are aware that the Analog

Setup Tool provides different hardware options for different

modules.

Default Chapter3
