Lesson 5 – Waveform Generation with the Mixed-Signal Tool

229

5-2 Starting the Mixed-Signal Tool

The Mixed-Signal Tool can be started from the Analog tab of the

SmarTest main tool bar.

Starting the Mixed-Signal Tool from the SmarTest Main Tool Bar

Mixed-Signal Tool
