Lesson 2 – Waveform Digitizer Setup with the Analog Setup Tool
167
2-1 Functions of the Analog Setup Tool
The Analog Setup Tool is used for configuring the analog modules.
NOTE The Analog Setup Tool works on a per-core basis. This means that you
first select an analog module core. All subsequent settings and
information refer to that core.
The term core has been chosen because some analog modules
comprise two completely independent instruments—which means
two cores. Most analog modules, however, have only one core.
Functions of the Analog Setup Tool
Hardware Settings
The hardware settings depend on the kind of module. They
include, but are not limited to:
• Input/output impedance
• Voltage range
• Offset voltage
• Lowpass filter
• Sample or sampling frequency
• Delay after trigger recognition
