Lesson 1 – Analog Modules

1-1 Summary of Analog Modules

The analog modules of the Agilent 93000 SOC Series can be

divided into two groups:

• Analog modules that source signals to the DUT

• Analog modules that measure signals coming from the DUT.

Each analog module has a three-letter identifier. This identifier is

used by SmarTest to refer to an analog module.

Analog Modules and their Software Identifiers

SOURCE: AWGs

• WGA: High Resolution AWG 1.024 Msps 18-bit

• WGE: 30M AWG 30 Msps 16-bit

• WGB: High Speed AWG 128 Msps 12-bit

• WGD: 500M AWG 500 Msps 12-bit

• WGC: Ultra High Speed AWG 2.6 Gsps 8-bit

• WGF: 4.1G AWG 4.1 Gsps 8-bit

• MCA: Multi-site Baseband Analog Source & Measure

• Audio AWG 1.024 Msps 24-bit

• Video AWG 100 Msps 14-bit

• (Audio/Video Digitizers)

MEASURE: Digitizers, Samplers, and Time Interval Analyzers

• WDB: High Resolution Digitizer 2 Msps 3 MHz BW 16-bit

• WDE: 20MHz Digitizer 5 Msps 20 MHz BW 16-bit

• WDA: High Speed Digitizer 41 Msps 100 MHz BW 12-bit

• WDG: 100MHz Digitizer 105 Msps 100 MHz BW 14-bit

• WDD: 1GHz Digitizer (digitizer mode) 320 Msps 160 MHz BW 12-bit

(sampler mode) 1 GHz BW 50 Msps 12-bit

• MCA: Multi-site Baseband Analog Measure

(or Multi-site Baseband Analog Source & Measure)

• Audio Digitizer 200 ksps 50 kHz BW 24-bit

• Video Digitizer 65 Msps 15 MHz BW/ 14-bit

100 MHz BW

• SPA: Dual High Speed Sampler 1 GHz max input 1 Msps 12-bit

• SPB: 3GHz Sampler 3 GHz max input 10 Msps 12-bit

• TIA: High Performance TIA 960 MHz max input

General Purpose TIA 400 MHz max input

Agilent Technologies 93000 SOC Series User Manual
