Lesson 1 – Multi-Site Test

521

Controlling the Setup/

Query-Focus State of

Site Manually

In addition to auto-controlling the setup/query-focus state of sites, you can

also control the state of setup-focus in the currently-active sites by using the

following APIs. The first two APIs specify which sites are addressed by

Setup APIs which follow, for performing the site-specific setup.

These APIs are meaningful in the first invocation block except for the each

site loop blocks.

The following shows an example program for the site-specific execution

using the multi-site APIs:

Getting the Site

Numbers

The site number information can be got by using the following APIs during

execution of your test method program:

• SET_TEST_FOCUS()

Sets the specified site(s) in the currently-active site(s) to setup-focus state.

This can also set all active sites except for the specified site(s) to non setup-

focus state simultaneously.

• UNSET_TEST_FOCUS()

Sets the specified site in the currently setup-focused site(s) to non setup-

focus state.

• GET_TEST_FOCUS()

Returns the number of the setup-focused sites and the site numbers.

ARRAY_I sites;

ON_FIRST_INVOCATION_BEGIN();

GET_TEST_FOCUS(sites); //Get setup-focused sites

SET_TEST_FOCUS(1); //Set only site 1

AWG("Ain").vOffset(5 V);

FLUSH();

SET_TEST_FOCUS(sites); //Restore setup-focused sites

ON_FIRST_INVOCATION_END();

• CURRENT_SITE_NUMBER()

Returns the site number of the current site under test.

• GET_CONFIGURED_SITES()

Returns the number of sites which were set up in the pin configuration, and

the site numbers

Agilent Technologies 93000 SOC Series User Manual
