23 — I-021G-P and I-241G-Q unit data sheet
Alcatel-Lucent 7302 ISAM | 7330 ISAM FTTN | 7360 ISAM FX ONT R04.06.02 November 2013 23-11
3FE 55873 AAAA TCZZA Edition 01
ONT Product Information Guide
Single-residence Gigabit Ethernet Package C ONTs with RF video and
without POTS
The single-residence Gigabit Ethernet ONT with RF video but without POTS
represents a variation of the Package C ONT. In the case of I-021G-P indoor ONTs,
the Package C ONT SoC-based functional block transmits Ethernet packets to up to
two one RJ-45 Ethernet ports and video packets to a coaxial port. This ONT also
features fiber optic and power connectors, as well as a reset button.
Figure 23-5 shows the functional blocks for a Package C ONTs with one Gigabit
Ethernet port and coaxial port.
Figure 23-5 Single-residence Gigabit Ethernet ONT with RF video and without POTS
Single-residence Gigabit Ethernet Package C with POTS, Ethernet,
and RF video
Figure 23-6 shows the functional blocks for I-241G-Q ONTs with four Gigabit
Ethernet, two POTS, and coaxial ports. This ONT has a triplexer and RF filter rather
than a diplexer.
Figure 23-6 Single-residence Gigabit Ethernet ONT with POTS and RF video (triplexer)
Ethernet
Power connector
F-type connector
RJ-45
21860
GPON
SOC
Optical
block
Power Converter
RF Video
Amp
Triplexer
POTS (2)
GigE (4)
RJ-11
Power connector
F-type connector
RJ-45
21050
GPON
SOC
Power Converter
Triplexer
RF Filter
