WSX-FT1/E1-SC Technical Speciļ¬cations
Number of ports 1 or 2 T1 or E1 ports
1 or 2 Universal Serial ports
Connector Types T1/E1: RJ-48C
Serial: High-density, 26-pin shielded
Standards Supported RFCs 1406, 1213, 1659
Frame Formats T1: Superframe, Extended Superframe, Unframed
E1: E1, E1-CRC, E1-MF, E1-CRC-MF, Unframed
Line Coding T1: B8ZS or AMI
E1: HDB3 or AMI
Data Rates Supported T1: 1.544 Mbps
E1: 2.048 Mbps
Serial: 56, 64, 128, 256, 384, 512, 768, 1024, 1536,
1544, 2048 Kbps
Compression Hardware-based using STAC 9705
Facility Datalink Protocol ANSI T1.403 and AT&T 54016
MAC Addresses Supported 4,096
Connections Supported Physical Data Terminal Equipment (DTE) or
Data Communication Equipment (DCE)
Cable Supported Serial Ports
DTE or DCE of the following types:
R2-232, V.35, X.21, RS-530, RS-449
Cable Distance T1/E1 (short haul): 200 meters
T1/E1 (long haul): 1829 meters
Power Consumption WSX-FT1/E1-SC-1W without an HRE-X: 5.75 amps
WSX-FT1/E1-SC-1W with an HRE-X: 7.25 amps
WSX-FT1/E1-SC-2W without an HRE-X: 7.25 amps
WSX-FT1/E1-SC-2W with an HRE-X: 8.75 amps
