The User Interface
Page 18-19
Token Ring Factory Default Translations
For Token Ring switching module ports the factory default is set to the following:
ATM LANE Factory Default Translations
For ATM LAN Emulation service ports the factory default is set to the following:
Token Ring Media - Default Mode
IP of any encapsulation is encapsulated SNAP
IPX encapsulations are encapsulated SNAP except for IEEE 802.2
which is forwarded as is.
Banyan Vines of any type are transmitted as LLC.
All other Ethertype and SNAP encapsulated protocols are sent as
for IP.
All other LLC encapsulated protocols are forwarded as is.
ATM LANE - Default Mode
No translations performed on Ethernet frames.
FDDI and Token Ring frames are translated to either SNAP or
LLC and are transmitted as such on ATM LANE.
Banyan Vines Token Ring and FDDI frames are translated to
Ethertype.
