Flash Memory and Omni Switch/Router Software
Page 2-7
Flash Memory and Omni Switch/Router Software
Flash memory on the MPX holds the Omni Switch/Router’s executable images and configura-
tion data. When a switching module comes online, the MPX downloads the appropriate image
file for that module to that module’s memory. Image files (those with the img extension)
contain executable code for different switching modules and software features.
The following table lists Omni Switch/Router image files that may be present in
MPX flash
memory along with the module(s) or feature with which the file is used.
File Name Modules/Function Used With
mpx.img
mpx.cmd
mpm.cfg
mpm.cnf
MPX
desx.img Ethernet port stress test software
diagx.img Diagnostics software
esx.img All GSX and ESX modules
fwdx.img IP Fastpath and Firewall software
gated.img Advanced Routing software
ipcntrl.img IP control software
ipms.img IPMS software
isdn.img WSX-BRI-SC
mrd.img Advanced Routing software
ntp.img Network Time Protocol (NTP) software
policy.conf PolicyManager file comprised of a MAC address and time that uniquely
identifies the switch(es) to which the policy applies
policy.img PolicyView software
qos.img Quality of Service (QOS) software
rav.img RADIUS authentication software
t1e1drv.img WSX-FT1/E1-SC
text_cfg.img Text-based configuration software
vrrp.img VRRP software
vsmboot.asc Boot file for Voice Over IP (VOIP) modules
vsx.img Voice Over IP (VOIP) modules
web.img HTTP browser client software
wsx.img WSX-S-2W, WSX-SC-4W, WSX-SC-8W (Frame Relay and PPP software)
