Omni Switch/Router Chassis and Power Supplies
Page 1-17
OmniS/R-9P-48V Technical Specifications
Total Module Slots 9
Total Slots for Switching Modules 8
Physical Dimensions 24.50” (62.23 cm) high, 16.60” (42.16 cm) wide,
13.25” (36.66 cm) deep
Weight 96 lb. (43.55 kg), fully populated with modules and power
supplies.
Switching Backplane Up to 22 Gbps (aggregate) switching fabric capacity
Voltage Range 40-60 VDC
Current Draw 23 Amps
Watts (Output) 725
Current Provided 120 Amps at 5.15 VDC
6 Amps at 12 VDC
6 Amps at 3.3 VDC
8 Amps at 1.5 VDC
Temperature Operating Range 0 to 70 degrees Celsius
32 to 158 degrees Fahrenheit
Humidity 5% to 90% Relative Humidity (Operating)
0% to 95% Relative Humidity (Storage)
Altitude Sea level to 10,000 feet (3 km)
Heat Generation 2219 BTUs per hour (one power supply)
Agency Listings UL 1950; CSA-C22.2 #950-M90; TUV EN60950; CB
Certification IEC 950; FCC Title 47 CRF Part 15, Subpart B
(Class A & Class B); IEC EN55022, 1995 (Class A & Class B)
CISPR 22, 1995; IEC 1000-3-2; IEC 1000-3-3 (EN60555-2); IEC
1000-4-2 (EN61000-4-2, per EN50082-1, 1992); EN55024 IEC
1000-4-3 (EN61000-4-3, per EN50082-1, 1992); IEC 1000-4-4
(EN61000-4-4) Level 4; IEC 1000-4-5 (EN61000-4-5) Level 4;
IEC 1000-4-6 (EN61000-4-6); IEC 1000-4-8 (EN61000-4-8);
IEC 1000-4-11 (EN61000-4-11); ENV 50204: 1996.
