Page 3-3

Required Image Files

See the table below for the required images files for the MPX and switching modules. You

must load the image file (or files) listed for the corresponding module or it will not run.

Required Image Files

Module Image File(s)

MPX mpx.img, fpx.img

ESX-K-100C-32W esx.img

ESX-K-100FM/FS-16W esx.img

GSX-K-FM/FS/FH-2W esx.img

VSX-VSA vsx.img, text_cfg.img, vsmboot.asc

VSX-VSD vsx.img, text_cfg.img, vsmboot.asc

WSX-S-2W wsx.img

WSX-SC-4W wsx.img

WSX-SC-8W wsx.img

WSX-BRI-SC-1W/2W wsx.img, isdn.img

WSX-FT1-SC-1W/2W wsx.img, t1e1drv.img

WSX-FE1-SC-1W/2W wsx.img, t1e1drv.img
