Omni Switch/Router Chassis and Power Supplies
Page 1-9
OmniS/R-3 Chassis Technical Specifications
Total Module Slots 3
Total Slots for Switching Modules 2
Physical Dimensions 5.25” (13.34 cm) high, 17.13” (43.51 cm) wide,
13.00” (33.02 cm) deep
Weight 18 lb. (8.18 kg), fully populated with modules and power
supplies.
Switching Backplane Up to 7 Gbps (aggregate) switching fabric capacity
Voltage Range 85-270 VAC, 47 to 63 Hz, auto-ranging and auto-sensing
Current Draw 3.8 Amps at 100/115 VAC
1.7 Amps at 230 VAC
Watts (Output) 200
Current Provided 32.8 Amps at +5 Volts
3 Amps at +12 Volts
Heat Generation Approximately 1020 BTUs per hour
Temperature Operating Range 0 to 45 degrees Celsius
32 to 113 degrees Fahrenheit
Humidity 5% to 90% Relative Humidity (Operating)
0% to 95% Relative Humidity (Storage)
Altitude Sea level to 10,000 feet (3 km)
Agency Listings UL 1950
CSA-C22.2
EN60950
FCC Part 15, Subpart B (Class A)
EN55022, 1987/EN50081
FCC Class B
C.I.S.P.R. 22: 1985
EN50082-1, 1992
IEC 801-2, 1991
IEC 801-3, 1984
IEC 801-4, 1988
VCCI V-3/94.04 (Class A & Class B)
EN 61000-4-2: 1995
EN 61000-4-3: 1995
EN 61000-4-4: 1995
EN 61000-4-5: 1995
EN 61000-4-6: 1996
EN 61000-4-8: 1993
EN 61000-4-11: 1994
ENV 50204: 1996
