Auto-Sensing 10/100 Ethernet Modules

Page 3-17

ESX-K-100C-32W Technical Speciﬁcations

Number of ports 32

Connector Type RJ-45

Standards Supported IEEE 802.3; IAB RFCs 826, 894

Data Rate 10 or 100 Mbps (full or half duplex)

Maximum Frame Size 1,518 bytes

MAC Addresses Supported ESX-K-100C-32W: 1,024

ESX-K-100C-32W4: 4,096

Connections Supported 10BaseT hub or device

100BaseTx hub or device

Cable Supported 10BaseT

Unshielded twisted-pair (UTP)

100BaseTx

Unshielded twisted-pair:

Category 5, EIA/TIA 568

Shielded twisted-pair

Category 5, 100 ohm

Maximum Cable Distance 100 m

Current Draw 10.25 amps without an HRE-X

11.75 amps with an HRE-X
