Omni Switch/Router Chassis and Power Supplies
Page 1-12
OmniS/R-5 Technical Specifications
Total Module Slots 5
Total Slots for Switching Modules 4
Physical Dimensions 12.25” (31.12 cm) high, 17.14” (43.54 cm) wide,
13” (33.02 cm) deep
Weight approximately 55 lb. (24.09 kg), fully populated with mod-
ules and power supplies.
Switching Backplane Up to 12 Gbps (aggregate) switching fabric capacity
Voltage Range 90-265 VAC, 47 to 63 Hz auto-ranging and auto-sensing.
Current Draw 6 Amps at 100/115 VAC; 3 Amps at 230 VAC
Watts (Output) 375
Current Provided 60 Amps at 5 Volts (V1)
5 Amps at 12 Volts (V2)
3 Amps at 3.3 Volts (V3)
5.1 Amps at 1.5 Volts (V4)
Temperature Operating Range 0 to 45 degrees Celsius
32 to 113 degrees Fahrenheit
Humidity 5% to 90% Relative Humidity (Operating)
0% to 95% Relative Humidity (Storage)
Altitude Sea level to 10,000 feet (3 km)
Heat Generation 1280 BTUs per hour (one power supply)
Agency Listings UL 1950
CSA-C22.2
EN60950
FCC Part 15, Subpart B (Class A)
EN55022, 1987/EN50081
FCC Class B
C.I.S.P.R. 22: 1985
EN50082-1, 1992
IEC 801-2, 1991
IEC 801-3, 1984
IEC 801-4, 1988
VCCI V-3/94.04 (Class A & Class B)
EN 61000-4-2: 1995
EN 61000-4-3: 1995
EN 61000-4-4: 1995
EN 61000-4-5: 1995
EN 61000-4-6: 1996
EN 61000-4-8: 1993
EN 61000-4-11: 1994
ENV 50204: 1996
