Fast (100 Mbps) Ethernet Modules
Page 3-20
ESX-K-100FM/FS-16W Technical Specifications
Number of ports 16
Connector Type MT-RJ
Standards Supported IEEE 802.3; IAB RFCs 826, 894
Data Rate 100 Mbps (full duplex)
Maximum Frame Size 1,518 bytes
MAC Addresses Supported 8,192
Connections Supported 100Base-Fx connection to backbone or server
Cable Supported Multimode: 62.5/125 micron multimode fiber
Single mode: single mode fiber
Optical output power Multimode: -19 to -14 dBm
Single-mode: -20 to -14 dBm
Optical receiver sensitivity Multimode: -31 dBm Max.
Single-mode: -31 dBm Max.
Cable Distance Multimode: approximately 2 km
Single-mode: approximately 15 km
Current Draw 9.75 amps without an HRE-X
11.25 amps with an HRE-X
