How Ports Are Assigned to Groups
Page 19-4
As the illustration below shows, the three ports are each moved from the default Group to a
Group with a policy that matches the subnet address of the workstation attached to the port.
AutoTracker IP address policies have been set up in Groups 2, 3, and 4. The ports are moved
to the Group with policies matching the subnet of the workstation.
Ports Move to Groups With Matching Policies
OmniS/R
12345678
123456
Port 2
Group 2
Group 1
Group 4
IP Network 130.0.0.0
Default Group
IP
Network 140.0.0.0
138.0.0.1 140.0.0.1
Group 3
IP Network 138.0.0.0
Port 3
130.0.0.1
Port 1
