This command displays three (4) layers of information. The top section provides information
on the physical interface. The middle section provides information on the logical, or Frame
Relay, interface. The third section provides information on the virtual circuits associated with
this physical port. The fourth section shows Frame Relay fragmentation information.
Frame Relay Status for slot 3, port 1:
Administrative/Operational Status …………………………………….. Up/Up
Speed Intf. Receive Receive Receive Transmit Signal
BPS Type CRC Errors Aborts Overruns Overruns Errors
======= ======= ========== ========== ========== ========== ========
2048000 V35DTE 18 12 0 0 2
Control DTR RTS DSR CTS DCD
Signal ON ON ON ON OFF
Frame Relay Information:
UniCast Discarded Error
Octets Frames Frames Count
========== ========== ========== ==========
IN 8962 120 2 0
Out 2650 24 5 0
IN+OUT 11612 144 7 0
Administrative/Operational Phase …………………………………….. Up/Up
Last Error Type ……………………………………......No Error Since Reset
Last Error Time ………………………………….....….. 0 Seconds
Interface failures ……………………………………........ 0
Last interface failure time …………………………………….. 0 Seconds
DLCI Information:
Admin/
DLCI Oper DLCI Frames Frames Octets Octets
Num Status Type In Out In Out
==== ====== ========== ========== ========== ========== =========
0 UP/UP Configured 10 10 160 140
31 UP/UP Learned 31 20 4196 1250
32 UP/DN Learned 145 110 4813 1450
Physical Level
Information
Logical (Frame
Relay) Infor-
mation
Virtual Circuit
Level
Information
Fragmentation
Information
Frame Relay Fragmentation Information:
DLCI Frag Size Frag Status In Frag Out frag Dropped Frag
==== ========= =========== ========= ======== ============
32 0 Disabled 0 0 0
